Price: sold by per foot (0.3 meter)The best stranded-core copper wire currently available.
Neotech UP-OCC Copper can be used as a mounting wire for internal wiring in audio components such as speakers, integrated amplifiers, CD-players etc.
Great for speaker cables, interconnects, mains cables and general hook-up wiring.
Neotech solid core wire is made from high-purity 7N UP-OCC copper sheathed in red, heat resistant teflon PTFE. Neotech has been producing outstanding cables since 1980, and has long been a leader in producing wire and cable using "single crystal" UP-OCC (Ultra Pure Ohno Continuous Cast), developed by Professor Ohno of the Chiba Institute of Technology in Japan.
UP-OCC is at least 99.99998% pure, and has an average crystal size of 125 meters (410 ft)! Compare this to the average crystal size of Oxygen Free, which is .02 meters (3/4"). The unidirectional UP-OCC has very low electrical resistance and practically no crystal boundaries.
Accordingly, it is able to transmit electrical signals faster and with less distortion than ordinary OFC and silver wires. All of these features make the pure OCC copper and silver the state-of-the art conductor materials for the audiophile cable industry.
Features & Specifications
- Conductor material: stranded-core UP-OCC copper
-
7 strands of 0.20mm wire
- Gauge: 0.22 mm² / 24 AWG
- Insulation: Red Teflon (PTFE)
- Cond. diameter: 0.54 mm
- Outer diameter: 1.3 mm
- Current rating: 300V/5.5A
